QT-Q58FD

Dual Polarized high gain dish base station antenna optimized for 5 GHz frequencie.
This antenna is ideally suited for multipoint applications where long range and wide coverage is desired. It is actually one antennas have 2 connector,horizontal polarized and vertical polarized for both ports. Rugged and Weatherproof.

Electrical:
Frequency Range Band width:  4950-5850MHz
Gain:  30dBi
Radiation:  Horizontal and Vertical
Horizontal Beam width:(H) 5.5°, (E)5.5°

Vertical Beam width: (H) 5.5°, (E)5.5°

V.S.W.R:<=1.5
Polarization: horizontal and vertical
Lightning Protection: DC grounded
Maximum Input Power: 100W
Impedance： 50Ώ
Connector：2xN Female
Antenna Radome Material: Aluminum Alloy

Mount way: Pole
Diameter of Installation Pole: Φ40-70mm

Mechanical
Antenna Dimension: Φ600mm
Weight: 15kg
Operating Temperature: -40°C to+60°C

Rated Wind Velocity: 210Km/h
