QT-Q5158F12

Omni-directional antennas are the right choice for situations where you need to be in contact with sources that are in two directions or if you do not know what direction the signals will be coming from. They may be mounted right side up or tipped upside down depending upon the desired pattern.
They also feature a very versatile clamp mounting system that will fit most every situation you
will encounter.

Electrical:
Frequency Range Band width:  5150-5850MHz
Gain:  12dbBi
Radiation:  omni direction
Horizontal Beam width: 360°

Vertical Beam width: 7°

V.S.W.R:<=1.5
Polarization: vertical
Lightning Protection: DC grounded
Maximum Input Power: 100W
Impedance： 50Ώ
Connector：N Female
Antenna Radome Material: Fiber glass

Mount way: Pole
Diameter of Installation Pole: Φ30-50mm

Mechanical
Antenna Dimension: Φ20x650mm
Weight: 300g
Operating Temperature: -40°C to+70°C

Rated Wind Velocity: 60m/s
RoHS Compliant: Yes
